FiiO M11 Plus MKII Digital Audio Player

This product is currently not available for purchase

Key Features

  • Revolutionary Android DAP
  • Take your hi-res music library wherever you go
  • Dual ES9068AS DACs provide superior audio fidelity
  • Snapdragon 660 CPU ensures smooth, efficient performance
  • Features a 5.5-inch touch panel for intuitive navigation and control

FiiO M11 Plus MKII Digital Audio Player Overview

The FiiO M11 Plus MKII Digital Audio Player combines audiophile-quality components, including dual ES9068AS DACs and a Snapdragon 660 CPU, to deliver a definitive portable hi-fi listening experience. Its sleek design features a bezel-less 5.5-inch display and innovative touch panel for volume control, making it not only a powerhouse of sound but easy to use.


With support for up to 2TB micro SD cards, the M11 Plus MKII can house a vast digital music library. It also features balanced and single-ended outputs to cater to a wider range of headphones and earphones. With an 11.5-hour battery life and Android 10 OS providing access to a plethora of apps, this player is a versatile companion for any music lover on the go.

Product Ref: 294666

Full Description

View Full Description

High-Resolution Audio Performance

The FiiO M11 Plus MKII pairs two ES9068AS DACs with THX AAA-78 amps, providing playback with unmatched fidelity and minimal distortion, for a soundstage so faithful, it feels live. Its high-performance DACs and anti-interference circuit design ensure clarity and depth in your music, enhancing your listening experience with every note.

Powerful Processing with Snapdragon 660

Powered by the Snapdragon 660 CPU, the M11 Plus MKII offers a struggle-free user experience. Whether you're navigating your music library, streaming online, or using Android apps, this player handles it all with ease. The processor is also efficient, contributing to the player's long battery life with low consumption and ensuring your music keeps playing for longer.

Extensive Connectivity Options

The M11 Plus MKII features high-res two-way Bluetooth V5.0 support and Wi-Fi music transfer, including AirPlay and DLNA streaming, enabling seamless access to your music library. With USB 3.0 for fast data transfer and charging, and 2.5mm, 3.5mm, and balanced 4.4mm outputs, this DAP fully accommodates your choice of high-fidelity headphones and amplifiers.

Intuitive User Interface

The FiiO M11 Plus MKII elevates user interaction with its innovative touch panel and physical buttons for precise volume control, complemented by a 5.5-inch 18:9 HD touchscreen for immersive visuals. It offers PEQ adjustments tailored for user audio tweaking and seamless navigation through Android mode, supporting a wide array of third-party apps, merging high-tech control with extensive functionality.

Robust Battery Life and Fast Charging

With a massive 6000mAh battery, the M11 Plus MKII delivers up to 11.5 hours of continuous music playback, and its three-hour fast charging quickly gets you back to your tunes. Perfect for long commutes or travel, it comes bundled with essential accessories: a tempered glass screen protector for durability, a stylish leather case for protection, and a Type-C USB 3.0 cable for easy charging and data transfer, ensuring you're fully equipped for any musical journey.

Versatile Audio Outputs

Crafted for the discerning traveller, the M11 Plus MKII showcases the robust sixth-gen honeycomb design complemented by a diamond-cut textured back, merging durability with elegance. Its innovative shortcut buttons and car mode feature enhance its easy usability when on the move. This sleek device not only stands up to travel demands but also ensures a seamless and intuitive listening experience wherever you go.

Features

  • Experience transparent audio with dual ES9068AS DACs
  • Smooth performance powered by the Snapdragon 660 CPU
  • Discover accurate sound reproduction with THX AAA-78 amps for a clear soundstage
  • DAP management is made easy with touch panel and button controls
  • Explore third-party apps like Tidal and Spotify with Android 10 OS
  • Access your music with AirPlay or DLNA compatibility
  • Store an extensive library, supporting up to 2TB micro SD cards
  • Features high-res two-way Bluetooth and WiFi transfer
  • Enjoy music all day with 11.5 hours of battery life and quick charging
  • Versatile listening options with single-ended and balanced outputs

What's in the box?

  • FiiO M11 Plus DAP
  • Tempered glass screen protector
  • Leather case
  • Type-C USB 3.0 data and charging cable
  • Coax cable
  • Quick start guide

Specifications

General

Name/Model M11 Plus
Hardware solution Soc: Snapdragon 660

DAC: ES9068AS*2

Amp: THX AAA-78*2

Bluetooth: QCC5124

USB: XMOS XUF208

NDK Femtosecond crystal oscillator*2
User Interface Android/Pure Music/USB DAC/Bluetooth Receiver/AirPlay mode
Colour Black
Size 136.6x75.7x17.6mm
Weight 295g
Display 5.5 inches(720*1440) fully fit screen
Volume control Slide or button control
RAM 4GB
ROM 64GB/≈46GB
TF card Single TF card slot, theoretically support up to 2TB
Gain control Low/medium/high
Channel balance L20 R20 (0.5dB/level)
Recommended headphone impedance 16 150Ω (SE output)/16 300Ω (BAL output)

Buttons and ports

Buttons Physical button + Touch Key + HOLD lock switch
USB Two-way TYPE C USB3.0 (charging/data transmission)
Phone Output 3.5mm single-ended+2.5mm balanced+4.4mm balanced
Line out (LO) 3.5 mm port (shared with PO)
COAX Output 3.5 mm port (shared with PO port. Supports up to 384kHz-24bit/DSD128)
Balanced Line out 4.4 mm port (shared with 4.4mm balanced PO)

Features

WiFi 2.4GHz/5GHz

DLNA

AirPlay

WiFi music transfer/Roon Ready
Bluetooth transmitter (5.0) SBC/AAC/APTX/APTX-HD/LDAC/LHDC
Bluetooth receiver (5.0) SBC/AAC/LDAC
FiiO Link WiFi and Bluetooth control (Android), WiFi control (IOS)
MQA MQA 8x unfold
All to DSD Yes
Double click to wakeup Yes
In-vehicle mode Would power on/off automatically when vehicle engine starts/stops
Sampling Rate Supported Up to Local playback: supports up to 384kHz-32bit/DSD256

USB DAC: supports up to 384kHz-32bit/DSD256
USB Audio 768kHz-32bit/DSD512 (DoP/D2P/Native)
Power-off timers Sleep/Idle power off
Equaliser 10-band EQ (±12dB)

8 presets+custom preset

custom EQ supported

PEQ supported
Firmware Upgrade Supports via zip file + TF card + OTA
Navigation control Gesture control/2-Bottom navigation/3-Bottom navigation

Power Supply

Power supply QC3.0, QC4.0, PD2.0 and PD3.0 fast charge
Battery capacity 6000mAh
Charging time 3.5h (QC4.0)
Standby time > 1000h

Battery life and test conditions

3.5mm headphone output: 14h Volume: 77

Gain: L

Screen: Off

Test File: MP3 44.1kHz/16bit

EQ: Off

Load: 32Ω
2.5mm+4.4mm balanced output: 14h Volume: 88

Gain: L

Screen: Off

Test File: MP3 44.1kHz/16bit

EQ: Off

Load: 32Ω

Audio parameters

PO output parameters (High gain mode)

Output power ≥300mW (16Ω / THD+N<1%)
Output impedance ≤1Ω (32Ω)
Output power ≥210mW (32Ω /THD+N<1%)
Crosstalk ≥76dB (1kHz/32Ω)
Output power ≥33mW (300Ω / THD+N<1%)
THD+N ≤0.00054 (1kHz/32Ω)
Noise floor ≤2.5μV (dbA)
SNR ≥122dB (dbA)
Frequency response 20Hz 20kHz (-1dB)

LO output parameters

THD+N ≤0.0006 (1kHz/10kΩ)
SNR ≥118dB (dbA)
Crosstalk ≥105dB (1kHz/10kΩ)
Noise floor ≤2.5μV (dbA)
Frequency response 20Hz 50kHz (-0.5dB)
LO Output Level 2.0V (1kHz/10kΩ)

PO balanced output parameters (High gain mode)

Output power ≥400mW (16Ω / THD+N<1%)
Output impedance ≤2Ω (32Ω)
Output power ≥660mW (32Ω /THD+N<1%)
THD+N ≤0.00085 (1kHz/32Ω)
Output power ≥90mW (300Ω /THD+N<1%)
Crosstalk ≥111dB (1kHz/32Ω)
Noise floor ≤2.5μV (dbA)
SNR ≥126dB (dbA)
Frequency response 20Hz 80kHz (-1dB)

LO balanced output parameters

THD+N ≤0.0004 (1kHz/10kΩ)
SNR ≥125dB (dbA)
Crosstalk ≥104dB (1kHz/10kΩ)
Noise floor ≤2μV (dbA)
Frequency response 20Hz 50kHz (-0.5dB)
LO Output Level 3.0V (1kHz/10kΩ)

File format support

Lossless DSD: DSD64/128/256/512, “.iso”,“.dsf”,“.dff”, DST iSO

DXD: 352.8K/24bit

APE FAST/High/Normal: 384kHz/24bit (MAX)

APE Extra High: 192kHz/24bit (MAX)

APE Insane: 96kHz/24bit (MAX)

Apple Lossless: 384kHz/32bit (MAX)

AIFF: 384kHz/32bit (MAX)

FLAC: 384kHz/32bit (MAX)

WAV:384kHz/32bit (MAX)

WMA LOSSLESS 96kHz/24bit (MAX)
Lossy MP3, OGG, WMA, AAC, etc.
