Audio Technica AT-LP120X Direct Drive USB Turntable, Black

Full Description

View Full Description

The LP120XUSB is the next generation of the critically-acclaimed LP120USB, features a new DC servo direct-drive motor, along with adjustable dynamic anti-skate control and selectable phono preamplifier. The fully manual turntable plays 33-1/3, 45, and 78 RPM records and is equipped with a USB output that allows direct connection to your computer. Just download the free Mac- and PC-compatible Audacity recording software (or software of your choice) and start converting your records to digital audio files. But in addition to the USB output, the turntable also comes with a detachable dual RCA output cable and is equipped with a built-in selectable phono preamp so you can connect directly to your home stereo, whether it has a dedicated phono input or not.

The turntable features an S-shaped tonearm with adjustable tracking force and an AT-HS6 universal ½"-mount headshell with an AT-VM95E Dual Magnet™ phono cartridge. Audio-Technica has been a leader in phono cartridge design for more than 50 years, and that expertise shows in the versatile, high-performance AT-VM95E cartridge, which comes with a 0.3 x 0.7 mil elliptical stylus, but is also compatible with any VM95 Series replacement stylus, offering a wide choice of options for every budget and application.

Additional features include a die-cast aluminum platter with felt mat; a start/stop button; selectable high-accuracy quartz-controlled pitch lock and pitch change slider control with +/-8% or +/-16% adjustment ranges; a stroboscopic platter with speed indicator; a removable plug-type stylus target light; external power supply; and a removable hinged dust cover.

• Direct-drive, DC servo motor.
• Fully manual operation.
• Adjustable dynamic anti-skate control.
• Selectable 33/45/78 RPM speeds.
• Convert records to digital files via the USB output.
• Professional anti-resonance, die-cast aluminum platter with felt mat.
• AT-HS6 universal ½’’- mount headshell and AT-VM95E Dual Magnet phono cartridge with 0.3 x 0.7 mil elliptical stylus.
• AT-VM95E cartridge is compatible with any VM95 Series replacement stylus, offering a wide choice of options for every budget and application.
• Balanced S-shaped tonearm with hydraulically damped lift control and lockable rest.
• Built-in switchable phono pre-amplifier for phono- or line-level output.
• Stroboscopic platter with speed indicator.
• Variable pitch control with quartz speed lock.
• Removable plug-type target light for easier cueing in low light.
• Damped base construction for reduced low-frequency feedback coloration.
• AC adapter handles AC/DC conversion outside of the chassis, reducing noise in the signal chain.

Type	Fully manual
Motor	DC servo-controlled
Speeds	33-1/3 RPM, 45 RPM, 78 RPM
Pitch Variation	+/-8% or +/-16%
Turntable Platter	Die-cast aluminum
Starting Torque	>1.0 kgf.cm
Braking System	Electronic brake
Wow and Flutter	<0.2% WRMS (33 RPM)
Signal-to-Noise Ratio	>50 dB
Output Level	Pre-amp “PHONO”: 4 mV nominal at 1 kHz, 5 cm/sec Pre-amp “LINE”: 240 mV nominal at 1 kHz, 5 cm/sec
Phono Pre-Amp Gain	36 dB nominal, RIAA equalized
USB Function	PC or Mac with an available USB port (USB1.1 or higher) Windows 7 or above, or Mac OS X or above A/D, D/A – 16-bit/44.1 kHz or 48 kHz USB selectable Computer interface – USB 1.1 Compliant Windows 7 or above, or MAC OS X or above
Power Supply Requirements	115/230V AC, 60/50 Hz
Power Consumption	3W
Dimensions	141,6 x 452 x 352 (H x W x D mm)
Weight	8.0kg
Accessories Included	AT-VM95E phono cartridge AT-HS6 headshell 1.9 m (6.2') USB cable Dual RCA (male) to dual RCA (male) cable with ground wire Counterweight Felt mat Dust cover 45 RPM adapter
Replacement Stylus	VM95 Series
